絕緣子型號 |
額定電壓KV |
最小電弧距離H.mm |
最小公稱爬電距離L.mm |
雷電全波沖擊耐受電壓KV（峰值）不小于 |
工頻一分鐘濕耐受電壓KV（有效值）不小于 |
|
FXBW-10/70 |
10 |
200 |
400 |
165 |
50 |
|
FXBW1-35/70 |
35 |
450 |
810 |
230 |
95 |
|
FXBW2-35/70 |
35 |
450 |
810 |
230 |
95 |
|
FXBW3-35/70 |
35 |
450 |
1015 |
230 |
95 |
|
FXBW4-35/70 |
35 |
450 |
1015 |
230 |
95 |
|
FXBW1-66/70 |
66 |
700 |
1450 |
410 |
185 |
|
FXBW2-66/70 |
66 |
700 |
1450 |
410 |
185 |
|
FXBW3-66/70 |
66 |
700 |
1900 |
410 |
185 |
|
FXBW4-66/70 |
66 |
700 |
1900 |
410 |
185 |
|
FXBW1-110/70 |
110 |
1000 |
2700 |
550 |
300 |
|
FXBW2-110/70 |
110 |
1000 |
2700 |
550 |
300 |
|
FXBW3-110/70 |
110 |
1000 |
3150 |
550 |
300 |
|
FXBW4-110/70 |
110 |
1000 |
3150 |
550 |
300 |
|
FXBW1-110/100 |
110 |
1000 |
2700 |
550 |
300 |
|
FXBW2-110/100 |
110 |
1000 |
2700 |
550 |
300 |
|
FXBW3-110/100 |
110 |
1000 |
3150 |
550 |
300 |
|
FXBW4-110/100 |
110 |
1000 |
3150 |
550 |
300 |
|
FXBW1-220/100 |
220 |
1900 |
5100 |
1175 |
540 |
|
FXBW2-220/100 |
220 |
1900 |
5100 |
1175 |
540 |
|
FXBW3-220/100 |
220 |
1900 |
6300 |
1175 |
540 |
|
FXBW4-220/100 |
220 |
1900 |
6300 |
1175 |
540 |
|
FXBW1-220/160 |
220 |
1900 |
5100 |
1175 |
540 |
|
FXBW2-220/160 |
220 |
1900 |
5100 |
1175 |
540 |
|
FXBW3-220/160 |
220 |
1900 |
6300 |
1175 |
540 |
